Tube to connector | Polyethylene HDPE |
Fluid | Air with blowing system |
Working Pressure | 20 bar |
MAX. Pressure | 28 bar |
Userful life | 25 years |
Tube assembly | No tooling required |
Water ingress test | 0.5 bar during 168 hours |
Working temperature | -45℃/+50℃ |
Transport and storage temperature | -10℃/+50℃ |
Installation temperature | -10℃/+50℃ |
Recommended blowing temperature | -15℃/+35℃ |
Outdoor exposure limit @Cetral Europe | 12 months |
Protection class | IP68 |
High pressure resistance(safety) | >50bar |
According to Standards | CEI EN 50411-2-8,EN 50411-2-5 |
Related documents | EN61300,EN61753-1,EN60068-2-10,EN60794-1-2:2003 |
Related documents | ISO 3601,ISO 4397:1993(2000),ISO4399:1995 |
Model | D | A | L | Weight(g) |
ERPUB3 | 3 | |||
ERPUB4 | 4 | |||
ERPUB5 | 5 | 13.5±0.2 | 14.3±0.5 | 1.86±0.1 |
ERPUB6 | 6 | 13.5±0.2 | 14.3±0.5 | 1.86±0.1 |
ERPUB7 | 7 | 15.2±0.2 | 19.2±0.5 | 2.6±0.1 |
ERPUB8 | 8 | 15.2±0.2 | 19.2±0.5 | 2.4±0.1 |
ERPUB8.5 | 8.5 | 15.2±0.2 | 19.2±0.5 | 2.4±0.1 |
ERPUB10 | 10 | 17.5±0.2 | 20.4±0.5 | 3.3±0.1 |
ERPUB12 | 12 | 21.5±0.2 | 23.5±0.5 | 5.85±0.1 |
ERPUB14 | 14 | 23.5±0.2 | 24.5±0.5 | 6.70±0.1 |
ERPUB15 | 15 | 25.3±0.2 | 25.8±0.5 | 7.80±0.1 |
ERPUB16 | 16 | 25.3±0.2 | 25.8±0.5 | 7.80±0.1 |
ERPUB18 | 18 | 32.7±0.3 | 27.8±0.5 | 15.05±0.2 |
ERPUB20 | 20 | 32.7±0.3 | 27.8±0.5 | 14.85±0.2 |
ERPUB25 | 25 | |||
ERPUB1/8 | 1/8 | |||
ERPUB3/16 | 3/16 | 13.5±0.2 | 14.3±0.5 | 1.86±0.1 |
ERPUB1/4 | 1/4 | 13.5±0.2 | 14.3±0.5 | 1.86±0.1 |
ERPUB5/16 | 5/16 | 15.2±0.2 | 19.2±0.5 | 2.4±0.1 |
ERPUB3/8 | 3/8 | 17.5±0.2 | 20.4±0.5 | 3.3±0.1 |
ERPUB1/2 | 1/2 | 21.5±0.2 | 23.5±0.5 | 5.85±0.1 |
